Certifications: ÖVE / ÖNORM E 8001-4-712, DIN V VDE 0126-1-1/A1, VDE AR N 4105, IEC 62109-1/-2, IEC 62116, IEC 61727, AS 3100, AS 4777-2, AS 4777-3, CER 06-190, G59/3, UNE 206007-1, SI 4777, CEI 0-16, CEI 0-21
Additional Information: The Light version does not include an installed Datamanager card for data transmission
Output Frequency: 50/60 Hz
Power Protection Functions: Overload protection
Warranty: 120 months factory warranty
Product Depth: 225 mm
Number of Phases: 3
Quantity: 1
Protection Class: I
Manufacturer Code: Eco 27.0-3-S Light
Product Color: Black, Gray
Number of MPP Trackers: 1
Max. Module Field Short Circuit Current: 71.6 A
Maximum Input Power: 37800 W
Apparent Power: 27000 VA
Real Power: 27000 W
Startup Voltage: 650 V
Input Voltage: 580 - 1000 V
Reverse Polarity Protection: Yes
Input Current (Max): 47.7 A
Output Current: 40.9 A / 39.1 A
Application: Solar Panel
Cooling Type: Forced Air Flow
Current Type: DC/AC
IP Protection Rating: IP66
Cooling System: Fan-cooled
Product Width: 510 mm
Topology: Transformerless
Power Supply Type: Indoor/Outdoor
USB: Yes
Product Weight: 35.7 kg
Built-in Display: Yes
Efficiency: 98.3%
Product Height: 725 mm
Grid Voltage Range: 3~NPE 380 V / 220 V / 3~NPE 400 V / 230 V (+20% / -30%)
