External panel. VIDOS X S10

External panel. VIDOS X S10

• CMOS AHD 1080p cameraCamera resolution : 2Mpix
• Lens viewing angle : 126° in width
• IR ( infrared ) night illumination
• Mechanical infrared filter
• Vandal-resistant aluminum alloy housing
• Front panel made of brushed stainless steel
• Angled mounting bracket included
• Illuminated call button
• Built-in potentiometer to adjust the volume of the door station
• Mechanical camera mode switch ( AHD / CVBS )
• Supports standard door openers, reversible door openers and electromagnetic jumpers
• Protection class : IP65
• Operating temperature range : -30 ~ 50°C
• Dimensions: 133mm(H) x 48mm(W) x 19.5mm(D)
• Surface mounting
• Power supply : from the monitor ( 12V DC )
• Output to electric door strike: relay, voltage free NO | NC

Works only with monitors in the VIDOS X series

• Model: S10
• Type of panel installation: On plaster
• Camera image sensor: CMOS AHD 1080p, 2Mpix
• Type of night lighting of the camera: Infrared LEDs
• Horizontal camera viewing angle: 126 °
• Dimensions in mm (sz. x height. x head.): 133mm(H) x 48mm(W) x 19.5mm(D)
• Cooperation with systems: VIDOS X
• Additional features: angle mounting bracket included, brushed steel panel
• Built-in camera: Yes
• Number of connecting wires: 4 + 2
