Haier Super Aqua 7.8 kW monobloc heat pump - YR-E27 Controller - ATW-A01 Control Module
Our bestseller
Haier Super Aqua 7.8 kW monobloc heat pump - YR-E27 Controller - ATW-A01 Control Module
- European Distribution Package: Haier Super Aqua Monoblock Heat Pump 7.8 kW AU082FYCRA(HW) with YR-E27 Wired Controller and ATW-A01 DHW Module Included
Brand
Entity responsible for this product in the EU
Refsystem Sp. z o. o.More
Address:
Metalowców 5Postal code: 86-300City: GrudziądzCountry: PolandE-mail: haier@haier-ac.pl
Symbol
AU082FYCRA(HW)
Producer code
6971026239221
Warranty
Energy class
A++
| Haier Monoblock Heat Pump – Air-to-Water for Central Heating and Hot Water | ||
|---|---|---|
| The modern SUPER AQUA heat pump allows configuration with various heat receivers and offers a wide temperature range for hot water, as well as the possibility to combine selected heating systems. | ||
|
Radiators An ideal solution when modernizing existing installations. The heat pump works excellently with conventional radiators, ensuring efficient heating. |
Underfloor Heating The SUPER AQUA system operates very efficiently with underfloor heating, leading to lower operating costs. |
Air-to-Water Fan Coil Units Perfect for both heating and cooling rooms, ensuring year-round comfort. |
|
|
|
|
Easy Installation and Maintenance Thanks to the Monoblock design, installation is quick and simple – the entire system is contained in one external unit and a control unit installed inside the building. The absence of an F-gas certification requirement and the use of the eco-friendly refrigerant R32 further enhance the efficiency and safety of the system. |
||
|
||
|
Reliable Operation in All Conditions
An intelligent sensor prevents the system from freezing. When the ambient temperature drops below 3 °C, the pump automatically starts to protect the equipment from damage. Additionally, a flow switch monitors the minimum water flow, ensuring system protection during cooling operation. |
Convenient Control Wired controllers allow easy selection of operating modes, schedule setting, and error history monitoring – significantly simplifying system management. |
Very Quiet Operation – 59 Decibels (dB(A))
Specially designed compressors, a quiet DC fan, and optimized blade geometry ensure minimal vibrations and an exceptionally quiet operation. |
Technical Data – Haier Heat Pump AU082FYCRA (HW):
| Power Supply (Phase/Voltage/Frequency) | 1/220-240/50/60 |
| Heating Capacity [kW] | 7.01 |
| Power Consumption (Heating) [kW] | 2.76 |
| Heating Capacity (Mode 2) [kW] | 7.8 |
| Power Consumption (Mode 2) [kW] | 1.77 |
| Cooling Capacity (Mode 1) [kW] | 7.0 |
| Power Consumption (Cooling, Mode 1) [kW] | 2.06 |
| Cooling Capacity (Mode 2) [kW] | 5.5 |
| Power Consumption (Cooling, Mode 2) [kW] | 2.34 |
| Coefficient of Performance (COP) – Heating | 2.54 |
| Coefficient of Performance (COP) – Heating, Mode 2 | 4.4 |
| Energy Efficiency Ratio (EER) – Cooling, Mode 1 | 3.4 |
| Energy Efficiency Ratio (EER) – Cooling, Mode 2 | 2.35 |
| Sound Pressure Level [dB(A)] | 64 |
| Water Flow [l/min] | 23 |
| Dimensions (Width/Height/Depth) [mm] | 950 / 965 / 395 |
| Weight [kg] | 87 |
| Refrigerant | R32 |
| Refrigerant Charge [kg] | 1.15 |
| Piping Diameter (Inlet/Outlet) [inches] | 1 |
| Operating Temperature (Cooling) [°C] | 10 ~ 46 |
| Operating Temperature (Heating) [°C] | -20 ~ 35 |
| Water Outlet Temperature (Cooling) [°C] | 5 ~ 20 |
| Water Outlet Temperature (Heating) [°C] | 20 ~ 55 |
| Wired Controller (included) | YR-E27 |
| Printed Circuit Board (PCB) for Hot Water Control (included) | ATW-A01 |
