Circulation pump Wilo-STAR-Z 20/7-3(150mm)
Special offer
Circulation pump Wilo-STAR-Z 20/7-3(150mm)
Brand
Entity responsible for this product in the EU
WILO-POLSKA SP.Z O.O.More
Address:
JEDNOŚCI 5Postal code: 05-506City: LESZNOWOLACountry: PolenE-mail: wilo.pl@wilo.com
Symbol
4081203
Producer code
4016322698067
Series
Warranty
Wilo Star-Z 20/7-3 circulating pump - High performance and durability
Product description
<S24.EU> The Wilo Star-Z 20/7-3 circulating pump is a high-quality device designed for domestic hot water (DHW) circulation systems. Thanks to its robust design and energy-efficient operation, it provides comfort and reliability for use in domestic and industrial installations.Key features
- Glandless pump with manual three-stage speed switching.
- Resistance to current when the motor is blocked.
- Body made of durable bronze (CC499K).
- Rotor made of fiberglass-reinforced plastic.
- Ceramic shaft with carbon resin-impregnated plain bearings.
Technical data
| Liquid temperature range | 2°C - 65°C |
|---|---|
| Maximum working pressure | 10 bar |
| Power consumption | 147 W |
| Rated current | 0,65 A |
| Rotational speed | 2797 rpm |
| Degree of protection | IP44 |
| Mounting length | 150 mm |
Application
The Wilo Star-Z 20/7-3 pump is designed for use in:
- Domestic hot water (DHW) circulation systems.
- Single-family and multi-family houses.
- Industrial and commercial facilities.
Advantages of the Wilo Star-Z 20/7-3 pump
Thanks to its robust design and modern technological solutions, the Wilo Star-Z 20/7-3 circulation pump guarantees:
- Efficient circulation of domestic water, providing quick access to hot water.
- Low electricity consumption.
- Long service life due to high quality materials.
- Easy installation and operation.
