Huawei photovoltaic inverter hybrid SUN2000-8K-MAP0 three-phase PV inverter energy storage 8 kW
- HUAWEI SUN2000-8K-MAP0 three-phase hybrid inverter for PV power conversion, AC power 8000 W, compatible with LUNA2000-S0 and LUNA2000-S1 energy storage.
Subscription products in your shopping cart
Set one delivery frequency for all subscription products in your cart every:
Subscription products in your shopping cart
HUAWEI SUN2000-8K-MAP0 hybrid inverter
The HUAWEI SUN2000-8K-MAP0 is an intelligent 8 kW three-phase hybrid inverter for new-generation photovoltaic installations. The device offers extremely high energy efficiency, advanced protection and full compatibility with Huawei LUNA2000 energy storage.
- AC rated power: 8,000 watts
- Maximum PV power: 14,600 Wp
- High efficiency: up to 98.6%
- 2 independent MPPT with a maximum current of 16 A
- IP66 rating and natural cooling
Product description
The HUAWEI SUN2000-8K-MAP0 inverter is the centerpiece of a smart energy system. With AFCI and RSD functions, connector temperature detection and three-phase asymmetrical load support, it provides the highest level of safety and reliability. It works with the LUNA2000-S0 and LUNA2000-S1 energy storage units, enabling efficient storage of surplus energy and emergency power supply in conjunction with the SmartGuard-63A-T0.
Key features
- Overloading up to 200% of power with asymmetrical three-phase loads
- Active protection: AFCI, RSD and connector temperature monitoring
- Cooperation with LUNA2000-S0 / S1 energy storage units
- High efficiency and low night loss (< 5.5 W)
- Compatible with SUN2000-450W-P2 and 600W-P optimizers
Technical data
| Parameter | Value |
|---|---|
| Model | SUN2000-8K-MAP0 |
| Maximum efficiency | 98,6 % |
| European efficiency | 98,0 % |
| Recommended max PV power | 14,600 Wp |
| Max. dc input voltage | 1100 V |
| Operating voltage range | 160 - 1000 V |
| Starting voltage | 160 V |
| Rated DC voltage | 600 V |
| Max. input current MPPT | 16 A |
| Max. short-circuit current | 22 A |
| Number of MPPT | 2 |
| Compatible energy storage | LUNA2000-5/10/15-S0, LUNA2000-7/14/21-S1 |
| Battery voltage range | 600 - 980 V |
| Max. battery current | 20 A |
| Max. charging power | 12 000 W |
| Max. discharge power | 8 800 W |
| Network type | Three-phase |
| AC rated power | 8 000 W |
| Max. apparent power | 8 800 VA |
| AC output voltage | 220/380 V, 230/400 V, 240/415 V |
| Max. output current | 13,3 A |
| Power factor | 0.8 inductive - 0.8 capacitive |
| THD harmonic distortion | ≤ 3 % |
| Cooling mode | Natural convection |
| Noise level | ≤ 29 dB |
| Dimensions (with handles) | 490 × 460 × 130 mm |
| Weight | 21 kg |
| Degree of protection | IP66 |
| Operating temperature | -25 °C ... +60 °C |
| Relative humidity | 0 - 100 % |
| Max. working altitude | 4000 m above sea level |
| Compatible optimizers | SUN2000-450W-P2, SUN2000-600W-P |
Technical data source:data sheet for model SUN2000-8K-MAP0 Link
FAQ - Frequently Asked Questions
- Does the SUN2000-8K-MAP0 inverter work with energy storage? Yes, it supports LUNA2000-S0 and LUNA2000-S1.
- How many MPPT tracks does the device have? The inverter has two independent MPPT tracks.
- What is the maximum DC input voltage? 1100 V.
- Does the device support failure mode? Yes, in combination with SmartGuard-63A-T0.
- What is the cooling of the device? Natural convection, without fans.
- What are the safety features? AFCI, RSD, overvoltage, overcurrent, overvoltage and connector temperature detection protection.
- What are the dimensions of the inverter? 490 × 460 × 130 mm.
- What safety standards does it meet? EN/IEC62109-1 and EN/IEC62109-2.
- What communication interfaces are available? RS485, WLAN, Ethernet, 4G (Smart Dongle).
- What is the maximum three-phase load? Support for 100% phase asymmetry.
- What is the battery discharge power? Up to 8,800 watts.
- What are the night losses? Less than 5.5 watts.
The HUAWEI SUN2000-8K-MAP0 is a state-of-the-art inverter with high efficiency, full integration with energy storage and advanced safety features, ideal for residential and commercial PV applications.
